説明
製品仕様と技術データ
非常に優れた高温安定性を備えた Ni-Cr 合金
- ✓良好な高温強度
- ✓高温での耐酸化性および耐浸炭性
- ✓優れた耐食性, さまざまなグレードに応じて増加します
- ✓Threaded flange features and benefits
- ✓インコロイをダウンロード 800 データシートと 825 データシート
インコネルと混同しないでください, Incoloy threaded flanges are made of a nickel alloy which contains iron and a lower content of nickel. インコロイは本質的にインコネルよりも経済的な選択肢です, 耐食性と温度制限はさらに制限されています. 通常, インコロイは酸化するため、高温環境に長期間さらされるのに最適な材料です。, 浸炭性と耐クリープ性. インコロイは耐海水性があるため広く使用されています。, 塩水, 高温の酸性ガスおよび高塩化物環境, そのため、石油、ガス、電力業界で人気の選択肢となっています。.
インコロイ フランジの最も一般的に使用されるグレードはインコロイです。 800, 800H, 800HT;インコロイ 825; そしてインコロイ 925. これらの特定のグレードの詳細については、, 当社の特定の Web ページにアクセスするか、当社のエンジニアリング専門家にお問い合わせください。:
インコロイのファスナーの種類: ボルト, ナッツ, ネジ, ねじ付きロッド, ワッシャー
利用可能なフランジのタイプ: ブラインドフランジ, 重ね継手フランジ, スリップオンフランジ, ソケットウェルドフランジ, ウェルドネックフランジ
フランジ寸法参考図
Incoloy Threaded Flanges Engineered for Heat and Corrosion Control
SASA FLANGE supplies incoloy threaded flanges manufactured from a nickel alloy containing iron and a lower content of nickel.
These flanges offer very good high temperature stability, good high temperature strength, and resistance to oxidization and carburization at elevated temperatures.
Corrosion resistance increases with the various grades, making them suitable for long-term service in high temperature steam, power plant systems, and petrochemical cracking environments where dependable threaded sealing and durable alloy performance are required.
Incoloy Threaded Flanges Grades, UNS Numbers, and Standards at a Glance
SASA FLANGE incoloy threaded flanges are commonly available in Incoloy 800, 800H, 800HT, 825, そして 925 成績.
の 800 series covers UNS N08800, N08810, and N08811 with ASTM B408, ASME SB408, ASTM B564, ASME SB564, EN 10204-3.1, and Werkstoff 1.4876, 1.4958, そして 1.4959.
インコロイ 825 は UNS N08825 under BS 3076NA16, ASTM B425, ASTM B564, ASME SB425, ASME SB564, DIN 17752, 17753, 17754, ISO 9723, 9724, 9725, and Werkstoff Nr 2.4858.
Incoloy Threaded Flanges Serving Demanding Energy and Process Sectors
SASA FLANGE incoloy threaded flanges are widely used in oil and gas service, especially where resistance to seawater, 塩水, 酸っぱいガス, and high chloride environments at elevated temperatures is needed.
発電において, they suit high temperature steam systems because the alloy maintains stable structure and strength during prolonged heat exposure.
In petrochemical and pilot processing lines, threaded construction is valuable when welding is dangerous or when frequent system reconfiguration is necessary.
Incoloy Threaded Flanges with Fast Delivery and SASA FLANGE サポート
選ぶ SASA FLANGE incoloy threaded flanges when you need a welded-free connection that saves installation time and cost in hazardous, 可燃性, or explosive applications.
They are also useful for small diameter pipes and materials that are difficult to weld successfully, although they are not suitable for high temperatures with frequent cyclic conditions or bending stress.
We offer made-to-order supply with 15-30 days production and ISO 9001:2015 quality assurance.
sales@sasaflange.com または WhatsApp にお問い合わせください +86 13764965049.
選ぶ理由 SASA FLANGE?
Multiple Pressure ClassesThreaded flange design supports applications where welding is not possible, though specific pressure classes are not stated in source content. |
Precise Dimensional TolerancesDesigned for threaded pipe connections using a tapered female thread to create a tight seal in service. |
耐食性Suitable for seawater, 塩水, sour gas and high chloride environments, with improved corrosion resistance in higher alloyed grades. |
ISO 9001 認定済みSource references ISO 9723, ISO 9724 そして ISO 9725 material standards for applicable Incoloy 825 仕様. |
Competitive PricingIncoloy is described as a more economical option to Inconel while still offering strong high temperature performance. |
Global ShippingSuitable for broad industrial use including oil and gas and power sectors, supporting international project supply requirements. |
incoloy threaded flanges Application Scenario
The incoloy threaded flanges is widely deployed across critical industrial sectors where reliable pipe sealing and pressure containment are essential. 典型的なアプリケーション シナリオには次のものがあります。:
高圧製油所の配管から都市配水ネットワークまで, the incoloy threaded flanges ensures leak-free connections and long-term service reliability in demanding environments.
incoloy threaded flanges installed in industrial piping system
よくある質問
Q: What is a incoloy threaded flanges used for?
あ: These flanges connect threaded pipe to valves, 継手, and equipment without welding, using a tapered female thread for leak-tight assembly. They are selected for corrosive and high-temperature service where Incoloy alloys outperform standard stainless steels. Typical applications include heat exchangers, 化学処理, オフショアシステム, sour service per NACE MR0175, and furnace or petrochemical piping using grades such as 800, 800H, 800HT, 825, そして 925.
Q: What materials are available for incoloy threaded flanges?
あ: Available materials include Incoloy 800, 800H, and 800HT for oxidation resistance and elevated-temperature strength; インコロイ 825 with molybdenum and copper for stronger resistance to sulfuric and phosphoric acids; そしてインコロイ 925, a precipitation-hardened nickel-iron-chromium alloy with high strength and corrosion resistance. Material selection depends on chloride exposure, サワーサービス, 動作温度, and mechanical load requirements. MTC is supplied to EN 10204 3.1.
Q: What pressure ratings does a incoloy threaded flanges support?
あ: Pressure class is not fixed in the provided specification and is supplied according to project requirement. Threaded designs are commonly produced to standard flange classes based on size, 合金グレード, ねじの形状, および使用温度. For Incoloy 800/825/925 アプリケーション, actual rating must be confirmed against ASME dimensions, 壁の厚さ, and operating conditions. SASA FLANGE can match the required pressure class for custom orders after technical review.
Q: What standards does a incoloy threaded flanges comply with?
あ: These flanges can be manufactured and certified to ASTM B408, ASME SB408, ASTM B564, ASME SB564, ASTM B425, ASME SB425, ASTM B637, BS 3076NA16, DIN 17752, DIN 17753, DIN 17754, VdTÜV 432, ISO 9723, ISO 9724, ISO 9725, ASME Code Case N-572, そして NACE MR0175 該当する場合. Material test certificates are provided per EN 10204 3.1 for full traceability.
Q: What is the lead time for custom incoloy threaded flanges orders?
あ: Custom orders typically require 15-30 日, depending on alloy grade, サイズ, 加工範囲, および認定要件. In-stock items can ship in 3-7 日. For custom threaded flanges in Incoloy 800H, 825, または 925, lead time may vary with raw material availability and thread specification. SASA FLANGE has over 15 years of manufacturing experience, は ISO 9001:2015 認定された, and supplies EN 10204 3.1 MTC. sales@sasaflange.com または WhatsApp にお問い合わせください +86 13764965049.
梱包と発送
📦 梱包は、荷物が最終目的地に到達するまでさまざまなチャネルを通過する国際輸送の場合には特に非常に重要です, そのため、すべての商品が完璧な状態で届くよう、梱包には特別な注意を払っています。.
SASA FLANGE 製品の種類と顧客の要件に基づいてさまざまな方法で商品を梱包します. 当社の標準パッケージオプションには以下が含まれます：:
- 合板ケース / 木箱 – 重量フランジおよび大径製品用
- シュリンクラップ付きパレット – 大量注文および標準サイズの場合
- 個別のポリ袋 + ダンボール箱 – 小さなフランジおよび継手用
- 防錆油塗装 + 耐水紙 – 長距離海上輸送用
- カスタムマーキングとラベル付け – 顧客の仕様またはプロジェクト要件ごと
すべての梱包は国際輸出基準を満たしています. リクエストに応じて特別な梱包指示を承ります.
