Monel 400 Elbow
Monel Alloy 400 Pipe Fittings are manufactured from a high-performance nickel-copper alloy (UNS N04400 / W.Nr. 2.4360) that offers excellent resistance to seawater, steam, salt solutions, and many corrosive chemicals. With outstanding mechanical strength and good weldability, Monel 400 fittings are widely used in marine engineering, chemical processing, oil and gas, and power generation industries. We supply a full range of fittings including elbows, tees, reducers, caps, and stub ends, produced according to ASTM B366 and ASME/ANSI standards. At SASA FLANGE, we ensure high quality, full material traceability, and competitive pricing, making our Monel 400 pipe fittings a reliable choice for demanding applications.
Specification of Monel 400 Pipe Fittings
| Dimensions | ASME B16.28, MSS-SP-43, ASME/ANSI B16.9, BS4504, BS10, BS4504, BS1560, |
|---|---|
| Thickness | SCH10, SCH 80, SCH 100, SCH20, SCH30, STD SCH40, SCH 160, XXS, SCH60, XS, SCH 120, SCH 140, available with NACE MR 01-75 |
| Type | DN15-DN1200 |
| Connection | Welding |
| Bending Radius | R=2D, 3D, 5D, 6D, 8D, 1D, 10D or Custom |
| Manufacturing process | Press, Forge, Push, Cast, etc. |
| Specialized manufacturer of | Tees, Crosses, Reducers, 90º Elbows, Stub End, Pipe Bend, 45º Elbows, Pipe Cap |
Various Sizes of UNS N04400 Fittings
- Alloy 400 Seamless ButtWeld Fittings : 1/2 – 10 inch
- Monel Alloy 400 Welded Pipe Fittings : 1/2″ – 48″
- Nickel 400 Fittings : ½” NB to 24″ NB
Available Nickel 400 Fittings Stock list
| Alloy Monel 400 Fittings | Monel 400 Pipe Fitting |
| Monel 400 UNS N04400 90 Degree Elbow | Nickel 400 End Cap |
| Alloy 400 45 Degree Elbow | Monel grade 400 Buttweld Fitting |
| ASTM B366 UNS N04400 1D Elbow | Monel Alloy 400 Short Stub End |
| Monel grade 400 Stub End | Alloy Monel 400 Pipe Cap |
| Monel 400 UNS N04400 3D Elbow | ASTM B366 UNS N04400 End Cap |
| Monel grade 400 5D Elbow | Monel 400 Reducer |
| Alloy Monel 400 Buttweld Fittings | Nickel 400 Pipe Bend |
| Alloy 400 Pipe Fittings | ASTM B366 UNS N04400 Long Stub End |
| Monel grade 400 Eccentric Reducer | Nickel 400 Long Radius Elbow |
| Monel Alloy 400 Concentric Reducer | Monel 400 UNS N04400 Short Radius Elbow |
| Alloy 400 Equal Cross | Monel 400 Pipe Cap |
| Alloy Monel 400 Lateral Tee | Nickel 400 Cross Tee |
| Monel Alloy 400 Reducing Cross | Monel grade 400 Equal Cross |
| Monel 400 Equal Tee | ASTM B366 UNS N04400 Stub End |
| Monel 400 UNS N04400 Concentric Reducer | Alloy 400 5D Elbow |
Types Monel 400 Fittings
| Types of Fittings | ||
|---|---|---|
 | |  |
| Pipe Cap | Pipe Elbow | Euqal-tee |
Chemical Composition of Alloy 400 Pipe Fittings
| Monel 400 | Ni | C | Al | Mn | Si | Fe | Cu | S |
| 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
Mechanical Properties of Monel Alloy 400 Seamless Fittings
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
Monel grade 400 Fittings Equivalent grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS |
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 |
