설명
제품 사양 및 기술 데이터
적당한 강도와 뛰어난 순도 및 내화학성
- ✓높은 순도와 낮은 추출물
- ✓산을 포함한 대부분의 일반적인 용매에 대한 화학적 내성, 염류, 기름과 증기
- ✓150°C까지의 기계적 강도 및 인성 (300°F)
- ✓자외선에 대한 저항, 핵 방사선, 및 표준 멸균 방법
- ✓풍화 및 곰팡이에 대한 저항성
- ✓PVDF 소재 데이터시트
- ✓스레드 플랜지 기능 및 이점
PVDF threaded flanges / Kynar® threaded flanges are made from a tough engineered fluoro-thermoplastic that offers a unique balance of excellent chemical resistance and good strength properties.
PVDF threaded flanges have the characteristic stability of fluoropolymers when exposed to harsh chemical and ultraviolet environments but are much stronger mechanically than PTFE or PFA polymers. PVDF threaded flanges also excel in high purity and low-permeability applications such as pharmaceutical and semi-conductor processing.
사용 가능한 플랜지 유형: 블라인드 플랜지, 슬립 온 플랜지, 소켓 용접 플랜지, 스레드 플랜지
플랜지 치수 참조
Precision Sealing Power with Pvdf Threaded Flanges
SASA FLANGE supplies pvdf threaded flanges manufactured from PVDF (Kynar), 뛰어난 순도를 지닌 견고한 엔지니어링 불소-열가소성 수지, 낮은 추출물, 광범위한 내화학성.
이 플랜지는 가장 일반적인 용매에 저항합니다., 산을 포함하여, 염류, 유화, 그리고 증기, 150°C까지 기계적 강도와 인성을 유지하면서 (300°F).
They also offer stability in harsh chemical and ultraviolet environments, 핵 방사선에 대한 저항성, 표준 살균 방법, 풍화, and fungi for dependable industrial piping performance.
Material Performance Data Behind Pvdf Threaded Flanges
The competitor data identifies pvdf threaded flanges as PVDF (Kynar) flanges with a threaded configuration using a tapered female thread to engage male threaded pipe and create a tight seal.
Confirmed properties include high purity, 낮은 추출물, 낮은 투과성, and mechanical strength and toughness to 150°C (300°F).
The material is chemically resistant to acids, 염류, 유화, 증기, and most common solvents, while being mechanically stronger than PTFE or PFA polymers in demanding service.
Process-Ready Pvdf Threaded Flanges for Critical Industries
SASA FLANGE pvdf threaded flanges suit chemical plants handling acids, 염류, 유화, 증기, and solvent service because PVDF delivers excellent chemical resistance and fluoropolymer stability.
In pharmaceutical and semiconductor processing, their high purity and low permeability support contamination-sensitive systems.
For oil and gas processing, 발전, 수처리, and marine installations, these flanges help where welding is unsafe, especially in hazardous, 가연성, or explosive areas, and in pilot systems that require frequent reconfiguration.
Act Fast on Pvdf Threaded Flanges from SASA FLANGE
선택하다 SASA FLANGE pvdf threaded flanges when you need a no-weld connection that saves installation time and cost, supports dangerous service conditions, and simplifies system changes.
재고 품목 배송 3-7 날, while custom orders typically move in 15-30 날.
Every order is backed by ISO 9001:2015 quality systems, 당 MTC EN 10204 3.1, PMI 테스트, 및 정수압 테스트.
sales@sasaflange.com 또는 WhatsApp에 문의하세요. +86 13764965049 오늘.
왜 선택해야 할까요? SASA FLANGE?
다양한 압력 등급Pressure class information was not provided in the source, but threaded design supports secure non-welded joining in suitable applications. |
정확한 치수 공차Tapered female thread design helps create a tight seal with male threaded pipe for reliable assembly performance. |
내식성Resists most common solvents including acids, 염류, 기름과 증기, while also performing in harsh ultraviolet environments. |
ISO 9001 인증됨Certification details were not listed in the source content; 연락하다 SASA FLANGE for available quality documentation. |
경쟁력 있는 가격Non-welded installation can save time and money, especially where welding is hazardous or impractical for the application. |
글로벌 배송SASA FLANGE supports industrial customers with prompt quotation assistance and export supply for global piping projects. |
pvdf threaded flanges Application Scenario
The pvdf threaded flanges is widely deployed across critical industrial sectors where reliable pipe sealing and pressure containment are essential. 일반적인 애플리케이션 시나리오는 다음과 같습니다.:
고압 정유 배관부터 도시 배수 네트워크까지, the pvdf threaded flanges ensures leak-free connections and long-term service reliability in demanding environments.
pvdf threaded flanges installed in industrial piping system
자주 묻는 질문
큐: What is a pvdf threaded flanges used for?
에이: These threaded flanges are used to connect PVDF piping, 밸브, and equipment in corrosive industrial service without welding. The tapered female thread provides a secure mechanical joint for high-purity and chemical process lines. Typical applications include acid transfer, 소금 용액, solvent handling, oil service, steam-exposed systems, and outdoor installations where resistance to UV, 풍화, 진균류, and standard sterilization methods is required up to 150°C (300°F).
큐: What materials are available for pvdf threaded flanges?
에이: This product is manufactured in PVDF, also known as Kynar, selected for high purity and low extractables in sensitive process piping. PVDF offers broad chemical resistance to most common solvents, 산을 포함하여, 염류, 유화, 그리고 증기. It also withstands ultraviolet exposure, 핵 방사선, 풍화, 진균류, 및 표준 멸균 방법. For applications requiring clean fluid service and elevated temperature capability, PVDF is the specified material option.
큐: What pressure ratings does a pvdf threaded flanges support?
에이: The pressure rating is application-dependent and should be confirmed against flange dimensions, 벽 두께, 결합 부품, media, and operating temperature. For this PVDF threaded design, temperature capability is rated to 150°C (300°F), but allowable pressure decreases as temperature rises. Because no fixed pressure class is specified, SASA FLANGE recommends providing service conditions, 스레드 세부정보, and line size so the correct rating can be verified before production.
큐: What standards does a pvdf threaded flanges comply with?
에이: No specific dimensional or pressure standard is listed for this PVDF threaded flange, so compliance is typically based on agreed drawing, 스레드 형태, and service requirements. The design uses a tapered female thread and is supplied to customer specification for industrial piping applications. SASA FLANGE 아래에서 운영 ISO 9001:2015 quality management and can provide material test certificates to EN 10204 3.1 where project documentation requires full traceability.
큐: What is the lead time for custom pvdf threaded flanges orders?
에이: Custom orders for these PVDF threaded flanges typically require 15-30 날, 크기에 따라, 수량, 스레드 사양, and any special machining or documentation requirements. If stock dimensions are available, 배송은 보통 3-7 날. SASA FLANGE 가지다 15+ 수년간의 제조 경험, operates to ISO 9001:2015, and can supply EN 10204 3.1 MTC. For quotations, sales@sasaflange.com 또는 WhatsApp에 문의하세요. +86 13764965049.
