A titanium blind flange is a flange without a center bore, designed to blank off the end of pipelines, 밸브, 슬리퍼, and pressure vessel nozzles. Compared with carbon steel and stainless steel alternatives, titanium blind flanges provide superior resistance to seawater, 염화물, oxidizing media and many aggressive chemical solutions, while also reducing system weight. They are widely used in offshore platforms, 담수화 장치, chlor-alkali plants, 열교환기, pulp and paper lines, 및 고순도 공정 시스템.
SASA FLANGE supplies titanium blind flanges in standard and custom dimensions to ASME B16.5, ASME B16.47, EN 1092-1, DIN, JIS 및 GB 표준. Each flange can be provided with chemical analysis, 기계적 테스트, 치수검사, PMI 테스트, EN 10204 3.1 인증서 및 전체 열 번호 추적성. Custom drilling, 직면 유형, thickness and non-standard pressure ratings are available on request.
- ✓제품 이름: Titanium Blind Flange
- ✓재료 등급: ASTM B381 F2 / F7 / F12, ASTM B265 Gr.1 / Gr.2
- ✓제품 유형: 블라인드 플랜지 / Blank Flange
- ✓주요 특징: Excellent corrosion resistance, light weight, strong sealing reliability
- ✓응용: 화학 처리, seawater service, 난바다 쪽으로 부는, 담수화, power and marine piping
제품 매개변수
| 제품 이름 | Titanium Blind Flange |
| 재료 등급 | ASTM B381 F1, F2, F7, F12; ASTM B265 Gr.1, Gr.2 |
| 재료 유형 | Titanium and titanium alloy |
| 제품 형태 | Forged blind flange, plate machined blind flange |
| 크기 범위 | DN15 – DN1500 (1/2 인치 – 60 인치) |
| 압력 등급 | 수업 150 – 2500 / PN6 – PN100 |
| 씰링면 | RF, FF, RTJ, TG, MFM |
| 표면 처리 | 절인, 부동태화된, 가공 마무리, glass bead blasted |
| 기준 | ASME B16.5, ASME B16.47 Series A/B, EN 1092-1, DIN 2527, JIS B2220, GB/T 9119 또는 고객 사양 |
| 점검 | 화학 분석, 기계적 테스트, PMI 테스트, 차원, 정수압 |
| 자격증 | EN 10204 3.1 재료 인증서 사용 가능 |
| 가공 서비스 | 절단, CNC 가공, 맞춤형 드릴링, 사용자 정의 크기 처리 |
화학 성분
The chemical composition below is for reference for common titanium flange grades used in industrial service. Final composition depends on the selected ASTM material grade and shall comply with the applicable standard, approved specification and mill test certificate. 중요한 프로젝트의 경우, SASA FLANGE can provide PMI verification and full traceability to the heat number.
| 요소 | 기음 | 그리고 | 망 | 피 | 에스 | Cr | ~ 안에 | 모 | 다른 |
|---|---|---|---|---|---|---|---|---|---|
| Gr.2 Titanium Content % | 0.08 최대 | 0.15 최대 | 0.03 최대 | 0.03 최대 | 0.015 최대 | – | – | – | 철 0.30 최대, 영형 0.25 최대, N 0.03 최대, 시간 0.015 최대, Ti balance |
기계적 성질
Mechanical properties of titanium blind flanges vary with grade, 단조 루트, 열처리 조건 및 단면 두께. The following values are typical minimum requirements for commonly specified titanium grades for flange applications. Exact values shall be confirmed by the corresponding material test report and project specification.
| 등급 | 인장강도 | 항복 강도 | 연장 | 경도 | 밀도 |
|---|---|---|---|---|---|
| ASTM B381 F2 | 345 MPa | 275 MPa | 20% 분 | 160최대 HB | 4.51 g/cm3 |
| ASTM B381 F12 | 483 MPa | 345 MPa | 18% 분 | 200최대 HB | 4.51 g/cm3 |
일반적인 크기 테이블
| 크기 범위 | 압력 등급 | 씰링면 | 재료 | 유효성 |
|---|---|---|---|---|
| DN15 – DN50 | 수업 150 – 600 | RF | Gr.2 Titanium | 재고 / 생산 |
| DN65 – DN300 | 수업 150 – 1500 | RF / RTJ | Gr.2 / Gr.7 Titanium | 재고 / 생산 |
| DN350 – DN600 | 수업 150 – 2500 | RF / RTJ | Gr.2 / Gr.12 Titanium | 생산 |
| DN700 – DN1500 | 수업 150 – 900 | RF | Gr.2 Titanium | 주문 제작 |
다양한 사양 비교
| 유형 | 설명 | 일반적인 사용 |
|---|---|---|
| ASME Blind Flange | Solid flange manufactured to ASME B16.5 or B16.47 with raised face, flat face or ring joint facing | 석유 및 가스, 석유화학, offshore and power piping systems |
| EN Blind Flange | Blank flange produced to EN 1092-1 with PN rating and metric dimensions | European process plants, water treatment and industrial utility systems |
| DIN Blind Flange | Blind flange according to DIN 2527 with DIN drilling and pressure designations | 화학공장, mechanical engineering and replacement projects |
| JIS / GB Blind Flange | Blind flange made to JIS B2220 or GB/T 9119 with regional drilling patterns and ratings | Asian industrial facilities, marine service and local standard projects |
동등한 표준 및 국제 이름
Titanium blind flanges can be supplied according to major international flange standards, while the base titanium material is selected from appropriate ASTM forging or plate grades. Equivalent designations may differ by region, but dimensional standards, drilling pattern and pressure rating can be matched to the required piping system and project code.
| 기준 / 지역 | 표준코드 | 일반 등급 / 동등한 |
|---|---|---|
| 미국 | ASME B16.5 | ASTM B381 F2, F7, F12 titanium blind flange |
| 유럽 | EN 1092-1 | Titanium blind flange in Gr.2 / Gr.7 to project material specification |
| 독일 | DIN 2527 / 2566 | Titanium blind flange equivalent to ASTM Gr.2 or Gr.12 |
| 일본 | JIS B2220 | Titanium blind flange in commercially pure titanium or corrosion resistant alloy grade |
| 중국 | GB/T 9119 | TA1 / TA2 equivalent or ASTM B381 F1 / F2 on request |
생산 공정 흐름
Titanium blind flange manufacturing requires strict control of raw material quality, forging condition, machining accuracy and contamination prevention. SASA FLANGE maintains process control from billet or plate selection through final inspection and packing to ensure dimensional accuracy, sealing performance and reliable traceability.
- 1. 원료 선택
- 2. 단조 / 절단
- 3. 열처리
- 4. 거친 가공
- 5. 마무리 가공
- 6. 교련
- 7. 표면 처리
- 8. 점검
- 9. 마킹
- 10. 포장
- 11. 배달
| 프로세스 단계 | 설명 | 품질 관리 포인트 |
|---|---|---|
| 원료 | Select certified titanium forging billets or plates | 재료 인증서 및 추적성 |
| 단조 | 필요한 형상을 얻기 위한 열간 단조 | 단조온도 및 압하율 |
| 열처리 | Stress relieving or annealing where applicable | 온도 및 유지 시간 제어 |
| 가공 | 씰링면, 볼트 구멍, 치수 | 치수 정확도 및 표면 조도 |
| 점검 | 배송 전 최종 검사 | 차원, 표면, PMI, 정수압 |
제품검사
1. 화학성분 검사
Chemical analysis is performed to verify the titanium grade meets ASTM requirements for elements such as iron, 산소, 질소, hydrogen and residual impurities. Incoming raw material certificates are checked against specification limits, and additional laboratory analysis can be arranged for critical applications to confirm compliance before production and shipment.
2. 기계적 성질 테스트
Mechanical testing confirms that the flange material satisfies required tensile strength, 항복강도, elongation and hardness values for the selected grade. Test records are reviewed against the applicable ASTM standard and project specification to ensure the titanium blind flange has adequate strength, ductility and service reliability under operating conditions.
3. 치수검사
Each titanium blind flange is inspected for outside diameter, 두께, 볼트 서클, bolt hole quantity, hole diameter, facing dimensions and overall tolerances. Sealing face finish and concentricity are also checked to ensure correct assembly with mating flanges, gasket seating integrity and compliance with ASME, EN, DIN, JIS or GB dimensional standards.
4. PMI 테스트 및 수압 테스트
PMI testing is available to verify the supplied flange material is the specified titanium grade and to avoid mixed material risk. Hydrostatic testing is conducted when required by project scope or assembly conditions. SASA FLANGE 용품 EN 10204 3.1 자격증, inspection records and traceability documents with each qualified shipment.
제품 포장
- ✓나무로 되는 케이스 포장: 고압, 대구경 제품에 적합
- ✓수축 랩을 사용한 팔레트 포장: 일괄 배송 및 표준 크기에 적합
- ✓방수 종이 + Foam Separation: Used for titanium surface protection during ocean freight
- ✓개별 비닐봉지 + 판지 상자: 소형 피팅 및 나사산 제품에 사용됩니다.
- ✓명확한 표시: 등급, 크기, 압력 등급, 히트 번호 및 PO 번호
응용
Titanium blind flanges are selected where conventional steel flanges are vulnerable to chloride attack, seawater corrosion or aggressive process media. Their excellent corrosion resistance, high strength-to-weight ratio and long service life make them suitable for demanding industrial systems requiring secure line blanking, maintenance isolation and dependable sealing performance.
| 산업 | 일반적인 응용 분야 | 이 제품을 사용하는 이유 |
|---|---|---|
| 석유 및 가스 | Offshore topside piping, produced water lines, seawater cooling systems, injection systems | Resists seawater corrosion, reduces maintenance and provides reliable end isolation |
| 화학 처리 | Chlor-alkali units, acid transfer lines, reactor nozzles, corrosive media piping | Excellent resistance to many oxidizing chemicals and long service life |
| 발전 | Condenser systems, flue gas desulfurization units, cooling water pipelines | Handles corrosive condensate and wet process conditions with low contamination risk |
| 수처리 | 담수화 플랜트, reverse osmosis skids, brine piping, seawater intake systems | Outstanding chloride and seawater resistance with low lifecycle cost |
| 해양 및 해양 | Shipboard cooling water systems, offshore modules, ballast and firewater piping | Light weight, high corrosion resistance and dependable flange sealing in marine environments |
왜 선택해야 할까요? SASA FLANGE?
- ✓Professional manufacturer of Blind Flanges for global industrial projects
- ✓맞춤형 크기, 도면에 따른 압력 등급 및 재료 등급
- ✓전체 표준 지원: ASME, EN, DIN, JIS, GB, GOST 및 고객 사양
- ✓열수 제어를 통한 재료 추적성 및 EN 10204 3.1 재료 인증서
- ✓화학 분석, 기계적 테스트, PMI 테스트, 정수압 및 치수 검사
- ✓표준 품목의 재고 가용성, 리드타임 3-7 날; 맞춤 생산 15-30 날
- ✓해상 수출용 포장, 항공 및 육상 운송
- ✓15+ 수년간의 경험 공급 50+ 전세계 국가
FAQ
큐: What is a titanium blind flange?
에이: A titanium blind flange is a solid flange without a bore used to close or isolate the end of a pipeline, 판막, pump or vessel nozzle. It is installed with bolts and a gasket against a mating flange to provide a secure pressure boundary. Titanium versions are chosen when corrosion resistance, low weight and long service life are critical.
큐: What materials are available for titanium blind flanges?
에이: SASA FLANGE commonly supplies titanium blind flanges in ASTM B381 F1, F2, F7 and F12 forging grades, as well as machined plate blinds from ASTM B265 Gr.1 and Gr.2 where applicable. Gr.2 is widely used for seawater and general corrosion service, while Gr.7 and Gr.12 are selected for enhanced corrosion or higher strength requirements.
큐: 지원되는 압력 등급?
에이: Titanium blind flanges can be produced in ASME Class 150, 300, 600, 900, 1500 그리고 2500, as well as EN and DIN pressure ratings such as PN6, PN10, PN16, PN25, PN40, PN64 and PN100. The available pressure class depends on size, 기준, material grade and project design requirements.
큐: 할 수 있다 SASA FLANGE 맞춤형 사이즈 공급?
에이: 예. SASA FLANGE supplies standard and non-standard titanium blind flanges according to customer drawings or project data sheets. We can customize outside diameter, 두께, 드릴링 패턴, 볼트 구멍, sealing face type, 표면 마무리, marking and material grade. Special dimensions for skid packages, replacement systems and offshore projects are available on request.
큐: 어떤 인증서가 제공되나요??
에이: SASA FLANGE 제공하다 EN 10204 3.1 material certificate with heat number traceability for titanium blind flanges. Supporting documents can include mill test certificate, chemical composition report, 기계적 테스트 결과, dimensional inspection report and PMI records. Hydrostatic testing can also be provided when specified by the order or project inspection requirement.
