Descripción
Especificaciones del producto y datos técnicos
A Ni-Cr alloy known for its corrosion resistance and high temperature stability
- ✓Good corrosion resistance at elevated temperatures
- ✓High temperature mechanical stability up to 2200°F (982°C)
- ✓High strength material with excellent toughness at elevated temperatures
- ✓Grados de Inconel: 600, 601, 625, 686, 718, 725, X750
- ✓In-depth insight on Alloy 625 and Alloy 718
- ✓Características y beneficios de la brida deslizante
- ✓Datasheets available on Inconel 625 e inconel 718
Inconel® slip on flanges, like Inconel 600, 601, 625, 686, 718 & 725 slip on flanges, are a family of nickel-chromium-molybdenum alloys used for their high strength at elevated temperatures and good corrosion resistance. Because of its high thermal stability, Inconel slip on flanges can be used in service temperatures ranging from cryogenic to 2200°F (982°C). The high alloy content of Inconel slip on flanges enable it to withstand a wide variety of severe corrosive environments. In mild environments, such as the atmosphere, sea water, neutral salts, and alkaline media, there is almost no attack to Inconel slip on flanges. In more severe corrosive environments the combination of nickel and chromium provides resistance to oxidizing chemicals, whereas the high nickel and molybdenum contents supply resistance to nonoxidizing environments.
Because Inconel slip on flanges offer a good balance of corrosion resistance, temperature stability, toughness and strength they are often a material of choice for chemical processing, aeroespacial, marina, electronics and oil & gas.
The most common grades of Inconel nickel alloy flanges are Inconel 625 e inconel 718. Gain more insight on these two grades by accessing our Inconel 625 e inconel 718 overviews or by contacting our engineering experts.
Tipos de bridas disponibles: Bridas, Bridas de junta solapada, Bridas deslizantes, Bridas de soldadura, Bridas roscadas, Bridas con cuello soldado
Referencia de dimensiones de brida
Inconel Slip on Flanges Built for Demanding slip on pipe flange Service
SASA FLANGE supplies Inconel Slip on Flanges as a family of Ni-Cr and nickel-chromium-molybdenum alloys valued for good corrosion resistance and high temperature mechanical stability.
These flanges perform from cryogenic service up to 2200°F (982°C), making each slip on pipe flange suitable for severe thermal duty.
Their high alloy content supports use in high temperature steam, sistemas de plantas de energía, and petrochemical cracking environments where toughness, fortaleza, and corrosion resistance must work together.
Inconel Slip on Flanges Grade Matrix and Standards Depth
SASA FLANGE offers Inconel Slip on Flanges in grades 600, 601, 625, 686, 718, 725, and X750.
Aleación 600 UNS N06600 resists carburization and oxidation through 2000°F; Aleación 601 UNS N06601 resists oxidation through 2200°F; Aleación 625 UNS N06625 is oxidation resistant to 1800°F and supports ISO 15156-3 y NACE MR0175-3; Aleación 718 UNS N07718 delivers creep-rupture strength to 1300°F.
Specifications cited include AMS, ASME, ASTM, EN, DIN, material, and UNS designations.
Inconel Slip on Flanges Across Heat, Químico, and Power Frontiers
SASA FLANGE Inconel Slip on Flanges are selected for chemical processing where oxidizing chemicals, ácidos reductores, and severe corrosive media demand durable sealing connections.
In marine and petrochemical cracking service, the material withstands atmosphere, sea water, scrubber environments, and pitting or crevice corrosion.
For high temperature steam systems, aerospace hardware, electrónica, petróleo y gas, and nuclear reactor related duty, these alloys combine elevated temperature strength, tenacidad, y estabilidad térmica.
Fast-Track Inconel Slip on Flanges from SASA FLANGE Hoy
Elegir SASA FLANGE for Inconel Slip on Flanges when buyers need a balanced combination of corrosion resistance, temperature stability, alta resistencia, and toughness in one slip on pipe flange solution.
We support made-to-order supply with 15-30 días de producción y ISO 9001:2015 seguro de calidad.
For urgent fast delivery requirements covering common grades like 625 y 718, contacta con sales@sasaflange.com o WhatsApp +86 13764965049 to discuss your application and sourcing schedule.
¿Por qué elegir? SASA FLANGE?
Múltiples clases de presiónPressure class data is not specified in source, while the product is presented for severe and elevated-temperature service applications. |
Tolerancias dimensionales precisasDimensional tolerance values are not specified in source, but slip on flange construction supports practical installation across industrial systems. |
Resistente a la corrosiónHigh alloy content helps resist atmosphere, sea water, neutral salts, alkaline media, químicos oxidantes, and nonoxidizing environments. |
ISO 9001 CertificadoISO 15156-3 is referenced in the source for Inconel 625, supporting recognized material specification requirements. |
Precios competitivosCommon grades such as Inconel 625 e inconel 718 support broad industrial use across chemical, marina, and energy sectors. |
Envío globalSuitable for international industries including aerospace, marina, electrónica, procesamiento químico, y aceite & aplicaciones de gas. |
slip on pipe flange Application Scenario
The slip on pipe flange is widely deployed across critical industrial sectors where reliable pipe sealing and pressure containment are essential. Los escenarios de aplicación típicos incluyen:
Desde tuberías de refinería de alta presión hasta redes municipales de distribución de agua, the slip on pipe flange ensures leak-free connections and long-term service reliability in demanding environments.
slip on pipe flange installed in industrial piping system
Preguntas frecuentes
q: What is a slip on pipe flange used for?
A: A slip on pipe flange is used to connect pipe, valvulas, zapatillas, and fittings where easy alignment and welding are required. The pipe slips through the bore, then fillet welds are applied inside and outside for strength. Inconel slip on flanges are selected for corrosive, alta temperatura, and cryogenic service, including oxidizing and chloride-containing environments, with alloy capability ranging from cryogenic duty up to 2200°F depending on grade.
q: What materials are available for slip on pipe flange?
A: SASA FLANGE supplies slip on flanges in Inconel 600, 601, 625, 686, 718, 725, and X750. These nickel-chromium and nickel-chromium-molybdenum alloys cover strong corrosion, oxidación, and high-temperature requirements. Common material designations include UNS N06600, N06601, and N06625, with EN grades 2.4816, 2.4851, y 2.4856. Material is produced to standards such as ASTM B166, B167, B168, B443, B446, and ASTM/ASME SB564.
q: What pressure ratings does a slip on pipe flange support?
A: La clasificación de presión depende de las dimensiones de la brida., grado del material, temperatura de funcionamiento, and the governing flange standard. For Inconel slip on flanges, SASA FLANGE manufactures to customer-specified pressure classes because the source data does not define a fixed class range. Temperature capability is grade-specific: Aleación 600 to 2000°F, Aleación 601 to 2200°F, Aleación 625 oxidation resistance to 1800°F, and Alloy 718 to 1300°F.
q: What standards does a slip on pipe flange comply with?
A: These slip on flanges are produced from Inconel materials compliant with major ASTM, ASME, AMS, EN, DIN, ISO, and NACE requirements. Covered specifications include ASTM B166, B167, B168, B443, B446, B462, B564, B574; ASME SB166, SB167, SB168, SB443, SB446, SB564; AMS 5540, 5665, 5666, 5837, 5596; EN 2.4816, 2.4851, 2.4856; ISO 15156-3; NACE MR0175-3. MTC is supplied per EN 10204 3.1.
q: What is the lead time for custom slip on pipe flange orders?
A: Custom slip on flange orders typically require 15-30 días, depending on Inconel grade, tamaño, alcance de mecanizado, y requisitos de inspección. Stock items are normally available in 3-7 días. SASA FLANGE ha terminado 15 años de experiencia en fabricación y opera bajo ISO 9001:2015 control de calidad. Each shipment can include EN 10204 3.1 certificados de prueba de materiales. Para horarios urgentes, contacta con sales@sasaflange.com o WhatsApp +86 13764965049.
